| Camera Specification |
|
| Sensor type | 1/2.8" Ultra low lux Exmor CMOS sensor |
| Lux Level(illumination) | Color 0.002 Lux, B/W 0.001Lux @(F1.2, AGC ON), 0Lux @ IR On |
| Shutter speed control | Auto/Manual, 1/2s ~ 1/100,000s |
| Gain control(AGC) | Yes |
| Lens | 2.8 ~ 12MM motorized lens |
| Focus control | Auto focus, One-key, Manual |
| Adjustable range | Dual filter ICR |
| ICR | up to 30mtrs., Smart IR control, IR LED power adjustable |
| IR distance | N.A |
| On Screen Display |
|
| WDR | 120dB, Auto/Manual adjustable |
| Day/Night | Auto(Outside/Inside), Color, B/W |
| Digital noise reduction | 3DNR (Close/Ordinary/Expert) |
| Light compensation | BLC Off/On, 1 Area, Customize design, HLC Off/On adjustable |
| White balance | Auto/Manual/Lock/Nature/Sunshine/Day Light/Warm Light |
| Other functions | Smart Defog control, EIS(Image Stabilizer), Flip control, Privacy masking |
| Motion detection | Yes, Zones :396(22x18), Sensitivity level 1~ 100 |
| Image control | Brightness, Contrast, Sharpness, Saturation |
| OSD display | 16×16,32×32,24×24,48×48,64×64 character size 5 area arrangement @ Time/Date/Week/Character/PTZ angle |
| Compression/Video/Audio |
|
| Video compression | H.265+, H.265, H.264, MJPEG, H.264 Main/High/Baseline profile |
| Video resolution | 5MP(1944P,1920P), 4MP(1520P)/3MP/2MP/1.3MP/1MP/D1/2CIF/CIF/VGA |
| Main stream | 5MP 2592×1944, 2560×1920, 4MP(2560x1520)/1080P(1920x1080)/960P(1280x960)/720P(1280x720)/D1(704x576) |
| Second stream | D1(704*576)/2CIF(704x288)/CIF(352x288)/QCIF(172x144) |
| Third stream | CIF(352x288)/QCIF(172x144) |
| Record & Live frame rate | Selectable 18 & 20fps at 5MP, 25fps at 4MP/3MP/2MP/1.3MP/1MP, second stream |
| Bit Rate | 32Kbps ~ 16Mbps, VBR/CBR, I-Frame interval |
| Audio compression & bitrate | G.711/G.726/ADPCM & 8K~48Kbps |
| Video Analysis |
|
| Intelligent video analysis | Crowd detection/Tripwire/Double tripwire/Perimeter/Missing and Foreign object/Fast Moving/Loitering/Parking/Blur image/Scene change/Audio & Video abnormal detection/People counting/Face detection |
| Intelligent alarm | Motion detection/Video loss/Video blind/Port alarm/IP & MAC conflict detection |
| Alarm & IVA trigger | On-screen alerts/PTZ trigger/Link out/E-MAIL/FTP upload/Pre-Post record |
| Corridor control | Yes(supported format 16:9, 9:16) |
| Region of Interest(ROI) | 4 Area |
| Advanced warning | Camera send early warning alert |
| Network, Storage, Interface |
|
| Protocol | TCP,UDP,HTTP,802.1x,FTP,SMTP,UPnP,Multicast,DNS,DDNS,NTP,RTSP,DHCP,PPPoE,SNMP,QoS,IGMP |
| Pre & Post recording | Pre : 5 to 15sec, Post : 10 to 60 sec |
| Storage function | ANR(auto download in NVR), Manual & Alarm recording |
| Network storage | FTP(pre & post upload) |
| LAN port | 1x Port RJ-45, 10M/100M ethernet |
| Storage | Micro SD/SDHC/SDXC slot(256Gb) |
| Two-Way Intercom | Built-in MIC, Built-in Speaker |
| Audio | 1Ch in, 1Ch out |
| Alarm | 2Ch in, 1Ch out |
| Other ports | RS-485, USB2.0 |
| Software Support |
|
| Onvif | Yes, Profile S |
| CMS software | iCRYS Series, up to 256CH(IP+NVR+Matrix) |
| 3rd Party VMS/NVR /CMS | Onvif/SDK/CGI |
| Mobile | Android /iOS through NVR, P2P cloud support |
| User login | 8 User / 4 level of rights, Simultaneous login <7 User client |
| Snap shots | Schedule, Link with FTP or Email |
| Encryption | Off/AES |
| General |
|
| Power supply | DC 12V & PoE (802.3af) |
| Power consumption | <5W @ IR Off, <8W @ IR On |
| Voltage protection | TVS 6000V, Lightning/Surge 2000V(power) 1000V(RJ45) |
| Language | English,Spanish,Korean,Italian,Turkish,Thai,Russian, Polish,French |
| IP & Vandal protection | IP66, IK10 |
| Reset switch | Yes |
| Operating temp. & humidity | -30°C ~ 60°C & 0% ~ 95% RH |
| Enclosure | Metal housing, Vandal plastic dome |
| Weight (g) & Dimension | <1Kg camera, Ø 145mm(D) X 125mm(H) |
| N.A |
